Module One: The
Part 3 - Releasing an Emulator
CONSPIRACY AND RETALIATION
OverClocked #10, "Spare Time" © 2000 David Lloyd
I still feel that most emulators ... are perfectly legal. It kinda falls into that "legal to own, illegal to use" category that seem to cover game copying devices and cable descramblers.Jeff Gerstmann, review editor, VideoGames.com
28 January 1999
marked a significant event in the world of videogame emulation. It
was on that day that a team of two hackers, known only by the aliases of
Epsilion and RealityMan, released
UltraHLE - the world's
first working emulator for the Nintendo 64 videogame console. Many
had tried over the previous year to devise an emulator for that system
and failed. Nintendo was well aware of the rising interest in emulating
its popular videogame systems, what with working NES and SNES emulators
already available, and they had strongly supported the IDSA sweep against
illegal Internet ROM sites during the spring and summer of 1998.
kept abreast of the growing possibility of N64 emulation and were the ones
behind the shutdown of Project Unreality, the most promising N64
emulation project of 1998. They threatened legal action if that project
produced a working N64 emulator, so the authors of Project Unreality
abandoned their efforts at that time. Both Epsilion and RealityMan
were already quietly conducting a parallel effort to develop a working
N64 emulator, but they decided to try a different approach than that of
the Project Unreality
team. Instead of starting with the console's
base functions and working upwards, they started with its high level functions
and worked down (hence the name
UltraHLE - Ultra High Level Emulator).
They also decided, in light of Nintendo's public attitude with regards
to emulation, that they would not tell anyone about their project until
they felt it was ready, and then make it available to as many people as
they could in the shortest amount of time.
The sudden and unexpected release of a working N64 emulator caught the emulation and videogame communities completely by surprise. What was even more insulting was that UltraHLE promised full compatibility with The Legend of Zelda: The Ocarina of Time (aka Zelda 64), the first N64 entry in the long-running and popular RPG series by Nintendo and its biggest seller of the 1998 Christmas shopping season. The release of a working N64 emulator promising full compatibility with their newest hit title was just too much to take, so it should not have surprised the emuscene when Nintendo reacted like it did. The blindsided videogame giant quickly rushed to shut down the UltraHLE website and threatened prosecution against the authors and anyone carrying or supporting UltraHLE, but it was too late. Epsilion and RealityMan's release tactics had ensured that UltraHLE would be spread far and wide given the nature of the Internet, and a helpless Nintendo could do little but watch as UltraHLE popped up on one site after another in quick and rapid succession. N64 cart dumps had already been available on the backwater sites for over a year, and now patrons of the "warez scene" had something with which to play their bootleg videogames. Zelda 64 was the most sought-after "ROM" of the lot, and it took little effort for dedicated Internet users to eventually track it down. UltraHLE was by no means perfect, and only worked with about one-third of the "ROMs" in existence at the time, but it worked with Zelda 64 and Super Mario 64 (the console's flagship title), and that was enough for most folks.
Nintendo's next reaction was what those familiar with its history might expect. It continued to threaten legal action against anyone who supported UltraHLE, and threatened to file suit against its authors claiming that the emulator was an infringing work that promoted software piracy. The threats were considered to be pure bluff by the emulation community and many sites called them on it - those that weren't carrying any bootleg N64 "ROMz," that is. As for the lawsuit threat against the UltraHLE authors, it is still looming as of this date, and the resultant legal pressures coupled with the instant popularity of UltraHLE among the software pirates forced the temporary "retirement" of RealityMan for a period of several months. In the meantime, Nintendo continued to flail away at the illegal N64 "ROM" sites whenever it found them, but it was of little use. At least two more sites would spring up for every one Nintendo managed to shut down, often hosted by unscrupulous ISPs and frequently in countries where Nintendo's famous legal resources were of little avail. Nintendo continues to maintain to this day that UltraHLE violated the patents and copyrights that it held on the N64 internals and microcode, including the system's anti-piracy security system. While the construction of UltraHLE remains a closely guarded secret even to this day, both Epsilion and RealityMan contend that it was an 100% reverse engineered software-based emulator; furthermore, the anti-piracy feature was not an issue because they did not emulate it (which would have been illegal). In the meantime, though, Nintendo's legendary intimidation tactics continue to be employed against anybody who carries UltraHLE and the requisite "ROMs," but the sad truth is that UltraHLE continues to be freely available and can be downloaded by anybody with the will to find it.
This incident caused some serious soul searching among the emulation community, as well as many a comment from the videogame industry. Most were of the opinion that UltraHLE should not be supported because it was designed to emulate a product that was very much alive and kicking. The release of UltraHLE implied that the end-days of the N64 were near, and nobody really believed that. On the other hand, there were those who argued that they should not discriminate against a supposedly legal emulator regardless of the status of the original system, and these were the folks who continued to carry UltraHLE on their web sites while the rest refused. The videogame community was equally split, with many expressing admiration for the programmers and their accomplishment while others called for their prompt prosecution. The debate seems to have died down after RealityMan announced his retirement from the emulation scene, and not long after UltraHLE reappeared on just about every single major emulation site. Those who had fought its support before now felt justified in carrying it after Nintendo's failed attempts to stop it; furthermore, they noted that there were several public domain "ROMs" available for it just as there were for other videogame emulators. The availability of a legally downloadable software base for the emulator, however limited and incompatible that might be, seemed enough justification enough to many minds for supporting this remarkable program. As an afterthought, it is ironic to note that Nintendo announced plans to release a new videogame console (the N2000, later renamed as the Dolphin) not long after the release of UltraHLE, so perhaps those who feared the N64's impending obsolescence may have been right after all.
In previous discussions, we have seen that emulation is a valid use for a computer system; furthermore, that an unlicensed emulator is possible once the intellectual property concerns are properly addressed. The time has now come for the next important step: the release of an unlicensed emulator.
In this and future
discussions, I will refrain from discussing pure firmware emulators, as
well as the more common varieties of hardware-software combinations.
Firmware emulators are almost always produced by original vendors or other
companies under license to the original vendor. Remember, the ability
of the Sega Genesis/MegaDrive to emulate a Sega Master System via VDP mode
4 was due to Sega itself and installed as a desire to support its customer
base for the older platform. Sony is taking the same position with
regards to the announced release of its newer PlayStation 2 console;
they have included a PlayStation emulation mode that permits playing of
many (but not all) older titles on the newer system. This is a practice
that is universally accepted within the industry; furthermore, firmware
emulators are quite profitable to the original vendor due to the proprietary
nature of such. It would be almost impossible to build a firmware
emulator without the consent of the original vendor, aside from the ubiqutous
cart adapters, and the laws are quite clear with regards to the illegality
of unlicensed clone products. Just ask all of the folks who tried
to manufacture the many unlicensed clones of the NES console during its
lifetime and see where it landed them.
A combination emulator is a different animal altogether, and their very nature tends to blur the legal lines somewhat. For example, Commodore's cross-licensing agreements with various PC clone manufacturers gave them solid legal ground upon which to base their PC Bridgeboard product for their Amiga computer systems. The same could be said of A-Max, as its only vendor-produced requirement was the use of the original Macintosh BIOS in its special hardware adapter - the Mac BIOS was the only truly proprietary part of the system - and this practice was eventually deemed acceptable. Jump forward in time to the present, where combo emulators have taken a new twist. The modern variety frequently require the use of a BIOS dump, which is nothing more than a software image of the computer code contained within the BIOS of the original system. Remember the A-Max bootleg? It's the same thing, but almost a decade later. I will reserve the discussion of the legality of this practice for another time, but will note in passing that such emulators have become widespread. For example, Cloanto of Italy sells a package called Amiga Forever designed expressly for users of the WinUAE Amiga emulator. Along with the emulator and other extras, it provides a legal copy of the AmigaDOS software, along with a legally licensed copy of the Amiga Kickstart ROM (the system BIOS, in other words). True hardware-software combos are becoming more rare with each passing day due to the incredible advances in computer processing capability, and the time will no doubt come when their existence will be limited to providing emulation for highly specialized niche systems that have a minimal impact at best upon the computer industry.
EMULATION AND REVERSE ENGINEERING
It goes without
saying that a pure software-based emulator should be comprised entirely
of reverse engineered code before you release it to the world.
This neatly avoids any legal claim that the original vendor can mount against
you in this regard, such as what happened between Intel and AMD over the
Am386 (Intel vs. AMD, 1991). The courts have ruled time and again
that reverse engineering does not void copyright protection, as it does
not replicate the original's "defining algorithms." A program written
entirely in 100% reverse engineered code is therefore legal, so it stands
to reason that any emulator that is 100% reverse engineered should also
be legal. The best way to do this is what is known as the "clean
room" technique, in which reverse engineered code is developed on the basis
of observing the actual operation of the original system and then coming
up with an independently developed means of duplicating its various processes.
The legality of the "clean room" technique was validated in the famous
legal dispute over the cloning of the IBM PC BIOS (IBM vs. Compaq, 1982).
The "clean room" technique is also the chief reason why Sony was unable
to prevent the bleem! PlayStation emulator from going to
market (Sony v. Bleem LLC, 1999), as the company had ample documentation
to prove that "clean room" techniques were used in every aspect of bleem!'s
design. This has established beyond the shadow of a doubt that the
legality of the "clean room" technique also applies to emulator development.
Another example you might consider is Steve Snake's KGen emulator
for the Sega Genesis/MegaDrive, which was also a "clean room" product.
It proved to be such a good program that Sega eventually licensed the source
code from the author for use in its commercially released Sega Smash
Pack. Talk about coming full circle!
As a final nod to the issue of of reverse engineering, let me share something with you from a leading major industrial organization with whom I have dealt in an indirect way for many years. One of the chief trade organizations in the electromechanical industry is the Institute of Electrical and Electronics Engineers (IEEE). You normally hear about them whenever there is a dispute about specifications for electrical or mechanical components; they are the industry's means of regulating itself. Here are some significant excerpts from their official policy statement regarding the concept and practice of reverse engineering which you might find interesting:
...We also believe that the high intellectual content of a computer product and competition are enhanced when computer products developed by one vendor are capable of operating with computer products developed by another vendor. This compatibility promotes the development of interoperable products by independent and competing vendors and, therefore, promotes enhanced value to the vendee at a competitive price....Pretty strong stuff, isn't it? And from one of the "big guns," too. These are the people who tell companies like Nintendo exactly how they can build their systems in such a way as to be considered safe for its users. The IEEE would not issue a policy statement with regards to the legality of reverse engineering and its underlying requirements unless they were absolutely sure of their facts. These facts were recently codified into law by the Digital Millenium Copyright Act, which I shall hereafter often abbreviate as the DMCA. Emulator developers should take this to heart whenever an original vendor begins making broad claims of copyright violation against them for the use of reverse engineered code. Such claims are frequently unfounded, and are almost always proven so when the issue is pressed in the courts.
We further believe that lawful reverse engineering of computer programs is fundamental to the development of programs and software-related technology.... We further believe that lawful reading, analysis, or disassembly of machine language is a reverse engineering technique by which an engineer can reconstruct the ideas of a computer program.
Accordingly, an engineer having the right to use a copy of a computer program should be entitled, without the authorization of the author, to observe, study, and test the functioning of the program, in order to determine the ideas that underlie the program, if it is accomplished while performing any of the acts of reading, displaying, running, transmitting, receiving, or storing the program or other lawful acts involving the program that the engineer is entitled to do.
We support the fair use rulings in the recent Appellate Court decisions in the Ninth and Federal Circuit, in Sega Enterprises vs. Accolade, 977F.2d 1510 (9th Cir. 1992) and Nintendo vs. Atari, 975F.2d 832 (Fed Cir. 1992) pertaining to disassembly of computer code.
THE PITFALLS OF EMULATION RELEASE
Finally, the day
arrives when you plan to unveil your emulator. Whether you are a
commercial company with considerable time and resources invested in your
product, or you're just an extremely gifted hacker like the one described
earlier, the time has come to make your creation known to world.
What happens next? Well, that depends on two things: who
originally vended the system you are emulating, and how old that
technology might be.
There has been a growing acceptance of emulation within the computer and videogame industry; however, it is not yet universal. Nintendo's attitude is well known and is embodied in their official emulation FAQ:
The UltraHLE [sic] is illegal. The N64 emulator infringes Nintendo's intellectual property rights, including copyrights, and circumvents Nintendo's anti-piracy security system.While you may not agree with their stance and not all of their contentions may be provable, it nevertheless highlights one extreme of the scale that original vendors use to measure emulation. A completely different approach is taken by Hasbro, now the owner of Nintendo's longtime competitor Atari, who recently released all rights for the now-defunct Atari Jaguar videogame system into the public domain:
We realize there is a passionate audience of diehard Atari fans who want to keep the Jaguar system alive, and we don't want to prevent them from doing that. We will not interfere with the efforts of software developers to create software for the Jaguar system.These are the two extremes you will have to face when deciding how the vendor will react to the release of your unlicensed emulator. Each company chooses to respond in a different way for different systems at any given time, so attempting to predict their behavior is not always successful.
Copyrights and trademarks of games are corporate assets. If these vintage titles are available far and wide, it undermines the value of this intellectual property and adversely affects the right owner. In addition, the assumption that the games involved are vintage or nostalgia games is incorrect. In fact, there are now more and more programs available that emulate current game systems such as Game Boy and the Nintendo 64.If you release an emulator for a product that is still on the market, you are presenting yourself as a direct threat to that product's market share. That fact, in retrospect, seems to be why Nintendo reacted as violently as it did to the appearance of UltraHLE. Epsilion and RealityMan boldly bragged about their emulator's ability to handle Zelda 64, along with other hit N64 cartridges at the time. UltraHLE directly threatened Nintendo's revenue stream on those titles, and that of the newly released Zelda 64 most of all.
THE A-MAX TEST FOR EMULATOR LEGITIMACY
It has taken me a lot of time, careful research, and a good deal of deliberation in order to come up with a generalized seven-point test that both the vendors and the emuscene can use to determine the legitimacy of any emulator that comes down the pike. I call it the A-Max test, so named after the emulator that established the possibility of unauthorized legitimacy in the first place. It works equally well for any product being emulated, from hand-held electronics to sophisticated computer and videogame systems. I will first present the test itself, then I will explain it, and then finish up with some examples of how it can be used to determine emulator legitimacy.
The original system's microcode is not duplicated.
(1)Uses original system BIOS ROMs in a legal fashion (actual chips in special adapter)I know that this analysis is going to have a lot of UltraHLE and PSEmu Pro users up in arms, to say the least, so let's see just why they failed the A-Max test.
(2) Licensing involved to clear legal hurdles
Up to this point,
we've talked about the basis for emulation. We've talked about developing
an emulator. We've just finished talking about releasing an emulator.
So what conclusion can we draw about emulation in general? Apply
Occam's Razor and draw the obvious one. As KGen author Steve
Snake recently noted in an Internet message board posting, "Emulation is
legal. It's that simple and not open to debate."
Commercial vendors can no more stop emulation than King Canute could order back the tide. Vendors with closed minds have little chance of stemming the production and subsequent release of emulators for their systems for very long, if ever at all. Other companies have tried to do so in the past with their systems and failed. It is legal for original vendors to develop their own emulators. It is legal for an independent developer to make their own emulator, provided it does not violate the original vendor's intellectual property rights. It is legal for an independent developer to release such an emulator without the original vendor's approval, provided that it can negotiate the legal hurdles in its path. Once those obstacles are overcome, then an independently developed unauthorized emulator has every right to be released to the general public.
We have now come to the end of the various discussions with regards to the legality of emulation. You should now know what is involved in developing, releasing, and possibly defending an independently developed unlicensed emulator. Now comes one of the biggest issues of all, and it represents (as the British would say) a "sticky wicket" indeed: "How do I support an emulator?" That will comprise our next big area of discussion.
1. Why is hardware-based emulation not considered to be a problem?
2. What particular issues do developers of emulators involving hardware-software combinations have to consider?
3. What is the best means of development in order to produce a legal unlicensed software-based emulator? Name two examples of such a product from the text or provide valid ones of your own. What does the IEEE have to say about this development practice?
4. What are two items of concern that independent developers must consider before releasing an unlicensed emulator?
5. What are the three primary arguments that vendors use whenever they sue the developers of an unlicensed emulator? What charges can you derive from those arguments?
6. How can an emulator developer defend themselves against charges of intellectual property infringement by the original vendor?
7. What is the truth behind "antipiracy security systems" in their current form? What are some ways to deal with this issue? Why do some emulator developers choose to ignore the problem in their products?
8. What does the release of an emulator usually indicate with regards to the original system? Why would this upset the original vendor?
9. Which is easier for a emulator developer to work with - program code within the original delivery format or an alternate format? Why?
10. How does software piracy affect the choice of delivery systems for a given vendor? How does this impact upon the release of an emulator?
11. What was the chief mistake committed by Epsilon and RealityMan concerning the release of UltraHLE? When is the right time for a developer to release an unlicensed emulator? Why?
13. What causes certain vendors to become concerned whenever an emulator is released for one or more of their systems?
14. Describe the hurdles that an emulator must jump in order to be considered a legal, noninfringing product. Why do some succeed and others do not?
15. Do you think that it is possible to release a legal third-party emulator? Why or why not?
THOUGHTS TO PONDER
1. If it is legal to design and then release an emulator, then is it legal to provide copies of the commercial software originally designed for use with the system being emulated?
2. Is it legal to dump a BIOS image in order to avoid having to create an emulator that would otherwise be a combination in design?
3. What is a "ROM?" Is there such a thing as a "legal ROM?"
4. Is it legal to backup computer software that was originally vended in some form of permanent storage format, such as a game cartridge or CD-ROM?
5. Can you define the concept of fair use? How does the concept of fair use apply to emulation?
6. How can the Internet legally support the emulation community?
